Page 9
GT490X
User Manual
Testing The System (Master & Main codes only)
1) With the display showing:-
2) Enter a Master or Main level code,
the display will show:-
3) Press NO, the display will show:-
4) Press NO, the display will show:-
5) Press YES to test the system
6) The display will show:-
7) Then for example:-
8) Pressing 1 will enter zone Status mode (All zones will show on the display
and will be deleted as each zone is triggered). Press 0 to escape.
Pressing 6 will silence the internal sounder,
Pressing 4 will toggle the Strobe On/Off,
Pressing 9 will toggle the Bell On/Off.
01 JAN 18 : 58 : 01
Do you want to . .
SET the System ?
Do you want to . .
REMOVE Zones ?
Do you want to . .
TEST the System ?
1=Status 4 = Strobe
6 = Sounder 9 = Bell
< All Zones ok >
TESTING . . .
To Next Page
