Technical Specification
Electrical
Battery Type
CR123, 3V Lithium battery (x 4)
Current Consumption
Standby current 9µA, Max current 150 mA
Power Output
868.65MHz: 10 mW
Frequency
433.92, 868.65, 915 MHz
Modulation Type
OOK
Typical Battery Life
3 years
Low battery indication
2.6 V
Proximity RF frequency
13.56 MHz
Physical
Dimension (HxWxD)
180 x 115 x 35 mm (7.1 x 4.5 x 1.4“)
Weight (Including batteries)
0.435 kg
Environmental
Operating temperature
-10°C to 55°C (14°F to 131°F)
Storage temperature
-20°C to 60°C (-4°F to 140°F)
Humidity Range
Average relative humidity: 75%
Standard Compliance
EN 50131-1, EN 50131-3 Grade 2,
Environmental Class II, EN 50131-6 Type C,
EN 50131-5-3, PD6662:2017
Certification body
Applica Test & Certification
Ordering Information
Model
Description
RW432KPP400A
WL Panda for LightSYS Keypad Prox, 433
RW432KPP800A
WL Panda for LightSYS Keypad Prox, 868
Standard Compliance
RED Compliance Statement:
Hereby, RISCO Group declares that this equipment is in compliance with the essential
requirements and other relevant provisions of Directive 2014/53/EU. For the CE
Declaration of Conformity please refer to our website: www.riscogroup.com.
