14
STEP 8
ASSEMBLY AND ADJUSTMENT
Foam Cushion
M10x130 Hex Bolt
NO. DESCRIPTION
QUANTITY
1
1
10
c
M10 Nut
M10 Washer
1
2
g
h
10
g
h
c
