15
STEP 9
ASSEMBLY AND ADJUSTMENT
Upper Handle Bar
M10x70 Square Neck Bolt
M10 Nut
M10 Washer
1
NO. DESCRIPTION
QUANTITY
2
2
2
11
b
g
h
b
g
h
11
