Ritmo BASIC 160 V1 - Parts Description (Continued); Facer;Heating Plate Support Components

3. PARTS DESCRIPTION ﻊﻄﻘﻟا ﻒﺻو
3./4
HEATING PLATE
7. Power plug
8. Handgrip
9. Welding temperature control thermometer (independent from thermoregulator)
10. Thermoregulator DIGITAL DRAGON (see § 4./3)
11. Pin for piston rod support
12. Plate
ﻦﻴﺨﺴﺘﻟا حﻮﻟ ﺔﻣﺎﻋد/ةاﻮﺴﻤﻟا
1.
ﺪﻴﻟا ﺾﺒﻘﻣ
2.
ﻦﻴﺨﺴﺘﻟا حﻮﻟ ﺖﻴﺒﻣ
3.
ةاﻮﺴﻤﻟا ﺖﻴﺒﻣ
.
1
2
3
4
1
5
6
3
2
