4. OPERATING INSTRUCTIONS
ﻞﻴﻐﺸﺘﻟا تﺎﻤﻴﻠﻌﺗ
4./14
4.6.1. Position the facer in between the ends to be welded
Rest the facer on the lower piston rod.
Anchor the facer at the upper piston rod with the help of the
blocking lever M.
4.6.2. Turn on the facer by pressing the start push button (green).
Approach and face both ends to be welded without overstressing the motor.
4.6.3. As soon as you get a continuous and uniformed (even) chip on both ends, stop the facing and open the
carriages.
Shut down the motor by pressing the stop push button (red).
Remove the facer and place it in its housing. Remove the chips without touching or fouling the faced ends.
M
