Ritmo BASIC 250 V1 - Dual Pressure Welding Cycle Explanation

2. WELDING GENERAL CRITERIA ﻠﻟا ﺮﻴﻳﺎﻌﻣﺔﻣﺎﻌﻟا مﺎﺤ
2./8
جودﺰﻤﻟا ﻂﻐﻀﻟﺎﺑ مﺎﺤﻠﻟا ةرود
مﺎﺤﻟ ﺪﻨﻋ جودﺰﻤﻟا ﻂﻐﻀﻟا ةرود مﺪﺨﺘﺴﺗ
PE 100 لدﺎﻌﻳ ﻚﻤﺴﺑ20 ذ قﻮﻔﻳ وأ ﻢﻠﻣﻚﻟ .
مﺎﺤﻟ ﺪﻨﻋ
PE 100 ﻦﻋ ﻞﻘﻳ ﻚﻤﺴﺑ20 ﻂﻴﺴﺒﻟا ﻂﻐﻀﻟا ةرود مﺪﺨﺘﺳا ،ﻢﻠﻣ)ﺔﻘﺑﺎﺴﻟا ﺔﺤﻔﺼﻟا .(
ﺔﻠﺛﺎﻤﺘﻣ ﻰﻟوﻷا ﻊﺑرﻷا ﻞﺣاﺮﻤﻟا) ةروﺪﺑ ﻖﻠﻌﺘﻳ ﺎﻤﻟ
ﺔﻄﻴﺴﺒﻟا ﻂﻐﻀﻟا.(
ﺔﻠﺣﺮﻤﻟا
5/6 مﺎﺤﻠﻟا .ﻦﻴﺘﻈﺤﻟ ﻲﻓ مﺎﺤﻠﻟا ﺔﻠﺣﺮﻣ ﻢﺘﺗ :
1 .ﻀﻟا ﺪﻨﻋ ﺾﻌﺒﻟا ﺎﻤﻬﻀﻌﺑ ﻊﻣ ﻦﻴﻓﺮﻄﻟا دﻮﺟو ﻰﻠﻋ ﻆﻓﺎﺣ ﻂﻐ)P
5
+P
t
( ﺖﻗﻮﻠﻟt
5
ﻞﻣﺎﻜﻟﺎﺑ .
2 . ﺔﻤﻴﻘﻟا ﻰﻟإ ﻂﻐﻀﻟا ﻞﻠﻗP
6
ﺖﻗﻮﻠﻟ ﺔﺴﻣﻼﻤﻟا ﻆﻓﺎﺣوt
6
ﻞﻣﺎﻜﻟﺎﺑ .
ﺪﻳﺮﺒﺘﻟا ﺔﻌﺑﺎﺴﻟا ﺔﻠﺣﺮﻤﻟا . ﺖﻗﻮﻟ ﻲﻜﻴﻧﺎﻜﻴﻤﻟا ﻂﻐﻀﻟا عاﻮﻧأ ﻦﻣ عﻮﻧ يأ ﻦﻣ ﻲﻧﺎﻌﻳ ﻻأو ﻞﺼﻔﻤﻟا ﻚﻓ ﻢﺘﻳ ﻻأ ﺐﺠﻳ
t
7
ﻞﻣﺎﻜﻟﺎﺑ .
DUAL PRESSURE WELDING CYCLE
The Dual Pressure cycle is used when welding PE 100 with thickness equal or superior to 20mm.
When welding PE 100 with thickness inferior to 20mm, use the Simple Pressure cycle (previous page).
The first four phases are identical (with
respect to the simple pressure cycle).
Phases 5/6 Welding. The welding phase happens in two moments:
1. Keep both ends together at the (P
5
+P
t
) pressure for the entire t
5
time.
2. Reduce pressure to P
6
value and maintain the contact for the entire t
6
time.
Phase 7 Cooling. The joint must not be removed or suffer any sort of mechanical strain for the entire t
7
time.
