4. OPERATING INSTRUCTIONS ﻞﻴﻐﺸﺘﻟا تﺎﻤﻴﻠﻌﺗ
4./8
4.4.1 ﺖﻗﻮﻟا ﻂﺒﻀﺑ ﻢﻗ )§ 3/.3(
ﺖﻗﺆﻤﻟا
1 : ﻦﻴﺨﺴﺘﻟا ﺖﻗو ﻂﺒﻀﺑ ﻢﻗt
2
.
ﺖﻗﺆﻤﻟا
2 : مﺎﺤﻠﻟا ﺖﻗو ﻂﺒﻀﺑ ﻢﻗt
5
)رودﻂﻴﺴﺒﻟا ﻂﻐﻀﻟا ة ( وأt
6
)جودﺰﻤﻟا ﻂﻐﻀﻟا ةرود.(
4.4.1 Set the time (§ 3./3)
Timer 1: Set the heating time t
2
.
Timer 2: Set the welding time t
5
(Simple Pressure cycle) or t
6
(Dual Pressure cycle).
4.4.2 ﻪﻴﺳﺎﺸﻟا ﺮﻀﺣ:
ﻰﻟإ عزﻮﻤﻟا عارذ ﻊﻓداﻞﻣﺎﻜﻟﺎﺑ تﻼﻣﺎﺤﻟا ﺢﺘﻓاو ﻰﺼﻗﻷا ﺪﺤﻟا.
Push the distributor lever to the maximum and open the carriages completely.
4.4.3 .تﺎﻀﻓﺎﺨﻟا ﻞﺧدأ ،ﺔﺟﺎﺤﻟا ﺪﻨﻋ:
4.4.3. If needed, insert the reductions
:
