Ritmo BASIC 250 V1 - Phase 5: Welding Process

4. OPERATING INSTRUCTIONS ﻞﻴﻐﺸﺘﻟا تﺎﻤﻴﻠﻌﺗ
4./21
PHASE 4: Reach of welding pressure
Pull the distributor lever with gradual increasing force until you reach the pressure (P
1
+P
t
) within the t
4
time.
= t
4
ﺔﺴﻣﺎﺨﻟا ﺔﻠﺣﺮﻤﻟا :مﺎﺤﻠﻟا
ﻂﻐﻀﻟا ﺖﺒﺛ.
=5 ٍن ا ﻮ ﺛ
عزﻮﻤﻟا عارذ رﺮﺣ.
ﺖﻗﻮﻟا ﻲﻬﺘﻨﻳ ﻰﺘﺣ ﺮﻈﺘﻧا
t
5
.
ﺖﻗﺆﻤﻟا
2
=
t
5
PHASE 5: Welding
Stabilize the pressure.
= 5 sec
Slowly release the distributor lever.
Wait for the t
5
time to end.
Timer 2
=t
5
