5Moduale Frontgestaltung VX25 / Modular front design VX25 / Aménagement modulaire de la face avant VX25
Frontblenden / Front trim panels / Bandeaux de fi nition
Best.-Nr.
Model No.
Référence
9682.314
9682.316
9682.318
9682.310
9682.312
9682.324
9682.326
9682.328
9682.320
9682.322
9682.334
9682.336
9682.338
9682.330
9682.332
9682.344
9682.346
9682.348
9682.354
9682.356
9682.358
9682.340
9682.342
9682.350
9682.352
Lieferumfang
Scope of supply
Composition de la livraison
H 100 mm H 300 mm H 100 mm H 300 mm
Befestigungswinkel / Mounting bracket / Equerres de fi xation
2 x3 x4 x5 x2 x3 x4 x5 x
Ø 23,6 (TX30) 2 x 3 x 4 x 5 x 2 x 3 x 4 x 5 x
M6 x 20 2 x 3 x 4 x 5 x 2 x 3 x 4 x 5 x
M6 2 x 3 x 4 x 5 x 2 x 3 x 4 x 5 x
M6 x 16 2 x 3 x 4 x 5 x 2 x 3 x 4 x 5 x
Trennsteg / Cross member / Traverse de séparation
- - - - 1 x 1 x 1 x 1 x
- - - - 2 x 2 x 2 x 2 x
M5 x 12 - - - - 2 x 2 x 2 x 2 x
Erdung / Earthing / Mise à la masse
1 x1 x1 x1 x1 x1 x1 x1 x
A 8,4 1 x 1 x 1 x 1 x 1 x 1 x 1 x 1 x
M8 1 x 1 x 1 x 1 x 1 x 1 x 1 x 1 x
Ø 8,2 x 16 1 x 1 x 1 x 1 x 1 x 1 x 1 x 1 x
Montageanleitung / Assembly instructions / Notice de montage
- - - - 1 x 1 x 1 x 1 x
1. Lieferumfang
1. Scope of supply
1. Composition de la livraison
