SP Range
Drawing 15
HBP MBP LBP
Mod.
S
[mm]
D
[mm]
Net. Weight [Kg]
Mod.
S
[mm]
D
[mm]
Net. Weight [Kg]
Mod.
S
[mm]
D
[mm]
Net. Weight [Kg]
Cond.Unit Evap. Cond.Unit Evap. Cond.Unit Evap.
SPH054__ 16 10 131.8 28.2 SPM054__ 16 10 94 27 SPL034__ 18 10 128 30
Drawing 16
MBP LBP
Mod.
S
[mm]
D
[mm]
Net. Weight [Kg]
Mod.
S
[mm]
D
[mm]
Net. Weight [Kg]
Cond.Unit Evap. Cond.Unit Evap.
SPM068*__
SPM080*__
22
22
12
12
117.4
130.7
46.6
51.3
SPL060*__
SPL080*__
28
28
12
12
144.4
145.7
46.6
51.3
Min.
Ø est.
set
off
on
set
off
on
