5.0 Main Menu Selections
5.1 Calibration
Power On
When the unit is powered on, the following “Ready
Menu” will display after a few seconds:
Verifier Ready
XXX Aperture: YY
XXX = indicates the wavelength (color) of the
light represented in nanometers
YY = indicates the aperture size in mils
Example:
660 Aperture: 10
This display indicates that the installed Auto Optic
uses red light at 660 Nanometer wavelength and a
10 mil diameter aperture size.
Press Enter and Select at the same time to bring up the
Main Menu:
Scan Calib Setup
Storage Inactive
D4000A Ver.x.xx
x.xx = Indicates the Software Version.
Press Select until the cursor is on CALIB and press
Enter.
D4000A Ver x.xx
Reflectance XX%
