8.0 Pass/Fail Analysis Screen
After the symbol is scanned the Pass/Fail Analysis
Screen may be displayed.
An example of an Pass/Fail Analysis Screen for an
acceptable symbol is shown below:
*1234ABCEDF456*
3of9 Pass AB-CDF
Grade A/06/660
4.0/06/660
This screen shows:
 The first line is the decoded data. (If more than 16
characters are present, those characters will wrap
to the next row of the display) Press Select to
scroll through the data
 The second line provides the following:
 Symbology type (if symbol accepted)
 The selected grades that pass or fail (grades to the
right of the dash fail are acceptable)
 The third line is the ANSI letter symbol grade
followed by the aperture diameter in mils (6
thousands inch in sample) and then the
wavelength in nanometers (660, indicating red, in
sample)
 The fourth line is the ISO numeric symbol grade
followed by the aperture diameter in mils (6
thousands inch in sample) and then the
wavelength in nanometers (660, indicating red, in
sample)
