5.3 Setup
Select Setup (from the Main Menu) to view various
system parameters:
 Press Select to choose an option
 Press Enter to initiate processing for that option
The first selection is Wavelength:
Wavelength
This selection allows you to select one of two light
wavelengths; toggle the two choices by pressing Select.
Wavelength
660nm, Red
Wavelength
925nm, Infra-Red
Press Enter to enable the selection.
The next selection is Aperture Size:
Aperture Size
.010 in.
Chose the Aperture size by pressing Select:
.003
in.
.006
in
.
(.005 for
Europe)
.010
in.
.020
in.
