The next selection is Passing Grade:
Passing Grade
B
Select one of the threshold grades, A, B, C, or D.
(See Appendix C for an explanation of ISO/ANSI grades)
The next selection is Output Device:
Output Device
TP140
Three output choices are available:
1. When TP140 is enabled, the data is output in the
format required by a TP140/TP140A printer
(The TP140A supports graphics)
2. When TP40 is enabled, data output is in the
format of analysis only
3. When Computer is enabled, data is output in
computer readable format (text and graphics)
(See Section 10.0, Connect to Computer)
The next selection is Auto Print Mode:
Auto Print Mode
Analysis+Profile
