Operator’s Guide Inspector D4000™ Auto Optic
002-5564 RJS, Minneapolis, MN
Three choices are available in Auto Print Mode:
1. Analysis Only: (For the TP140A / TP140 / TP40 /
Computer) Both ISO/ANSI and Traditional analysis
will print automatically after a symbol is scanned.
2. Analysis+Profile: (For the TP140A / Computer)
Scan reflectance profile graph will be added to the
analysis only printout.
3. Off: You must press the print button to print.
(See Appendix H - Print Functions)
The next selection is Scans/Analysis:
Scans/Analysis
Single
From this screen you may choose the number of scans
(from 1 (single) to 10) to be used in the analysis.
The next selection is Decode 3 of 9 as:
Decode 3of9 as
Code 3of9
This selection is for choosing the Code 39
sub-specifications for analysis:
Code 3 of 9
3of9 w/43
AIAG B-1
AIAG B-3/4/5/10
LOGMARS
HIBC 3 of 9
If either AIAG choice is entered, the RJS Inspector
D4000 will automatically perform the scan reflectance
profile analysis per the AIAG grading thresholds and
display numbers 4, 3, 2, 1 and 0 in place of the letter
grades.
