RKC INSTRUMENT PF Series User Manual

3. WIRING
IMR02L04-E3
3-4
 Up to two solderless terminal lugs can be connected to one terminal screw.
However, in this case, reinforced insulation cannot be used.
Bend the solderless terminals for multi-drop wiring to avoid damage to the screws by
securing forcibly. (Refer to Fig. 3.3)
If two solderless terminal lugs are connected to one terminal screw, a terminal cover cannot be
used.
Fig. 3.3 Image of how to bend each solderless terminal lug
Top view
Panel
