The notebook should not be subjected to vibration or shock. Always
transport your notebook in its original packing material.
USB Connector
The mainboard provides a Universal Host Controller Interface Universal
Serial Bus root for attaching USB devices like keyboard, mouse, etc. You
can plug the USB device directly to this connector.
PIN Signal
1 VCC
2 -Data
3 GND
4 +Data
System Setup (CMOS) Program
The BIOS has a built in setup program which allow the user to modify the
notebook's basic system parameters. This information is stored in the battery
backed CMOS memory.
Your notebook has been set up by RM and is ready to use.
Use the CMOS Setup program to change the system settings if:
– you change the amount of memory in your notebook
– you add or change a disk drive
– you want to change the password
– you want to set up special features.
CAUTION: Do not attempt to run Setup and change the system settings
unless you understand what you are doing. You can experience serious
problems when using your notebook if you select incorrect settings in Setup.
Full details on entering, changing the system settings and saving changes
and exiting are in the System Board User’s Manual (if supplied).
Important: Before changing any system settings make a record of all current
settings first.
