RS5 OWNERS MANUAL
13
Handlebar Installation
0 1
Using a number 4 hex key, remove all four
bolts from the handlebar bracket and set
them aside with the top bracket.
0 3
Align the top piece of the handlebar bracket over
the handlebar and bottom bracket. Reinsert the four
bolts and tighten them evenly.
05
Adjust the display to the desired angle and
tighten the display bracket.
06
Position the control module, brakes, and
throttle to your preferred angles, then
tighten all components securely.
04
Adjust the handlebar angle for easy access to the
brakes, control module, and throttle. Ensure the
handlebar is secure and does not rotate or shift.
0 2
Place the handlebar on the lower bracket,
centering it properly.
