RX7 OWNERS MANUAL
15
Handlebar Installation
0 1
Using a number 4 hex key, unscrew all four
bolts on the handlebar bracket and remove
it. Set the screws and the top bracket aside.
0 3
Position the top piece of the handlebar
bracket over the handlebar and align it with
the bottom piece of the handlebar bracket.
Insert the 4 screws back into the handlebar
bracket. Ensure the angle of the handlebar
allows easy access to the brakes, control
module, and throttle. Tighten all four screws
so the handlebar does not rotate or move
side to side.
05
Adjust the control module, brakes, and
throttle to the desired angles, then tighten
all components so they do not move.
04
Adjust the display to the
desired angle and tighten
the display bracket so it
does not move.
0 2
Place the handlebar on
the lower handlebar
bracket and center it.
