4. Installation
4.1Fitting/Exchanging the lamp
DANGER !
Install the lamps with the device switched off only.
Unplug from mains before !
To insert the lamp open the small cover at the rear panel (see the drawing) by loosening the 2 Phillips screws "A"
and "B" on the cover.
Gently pull out the lamp assembly.
If changing the lamp, remove the old lamp from the socket. Insert the lamp to the socket.
Do not install a lamp with a higher wattage! A lamp like this generates temperatures the device is not designed for.
Damages caused by non-observance are not subject to warranty. Please follow the lamp manufacturer‘s notes!
Do not touch the glass-bulb bare hands during the installation! Make sure that the lamp is installed tightly into the
lampholder system.
Reinsert the lamp assembly and tighten the 2 screws again.
Do not operate this fixture with opened housing-cover!
Screw "B"
Screw „X”
Screw „Z”
Screw „Y”
Screw "A"
