0 - 255 Pan movement by 540°
proportional
2 * 2
0 - 255 Fine control of pan movement
proportional
3 2 3
0 - 255 Tilt movement by 270°
proportional
4 * 4
0 - 255 Fine control of tilt movement
proportional
5 3 5
Pan/Tilt speed , Pan/Tilt time
0 Standard mode
step
1 Max. Speed Mode
step
Pan/Tilt speed mode
2 - 255 Speed from max. to min.
proportional
Pan/Tilt time mode
2 - 255 Time from 0.2 s to 25.5 sec.
proportional
6 4 6
0 - 9 Reserved
To activate following functions, stop in DMX value for at least 3 s
and shutter must be closed at least 3 sec. („Shutter,Strobe”
channel 22/15/27 must be at range: 0-31 DMX). Corresponding
menu items are temporarily overriden except DMX Input.
10-14
DMX input: Wired DMX*
step
15-19
DMX input: Wireless DMX*
step
* Function is active only 10 seconds after switching fixture on
20-24
Eco mode ( Lamp power 230W)
step
25-29
Standard mode (Lamp power 280W)
step
30-49
Reserved
50 - 59 Pan/Tilt speed mode
step
60 - 69 Pan/Tilt time mode
step
70 - 79 Blackout while pan/tilt moving
step
80 - 89 Disabled blackout while pan/tilt moving
step
90 - 99 Blackout while colour wheel moving
step
100 - 109 Disabled blackout while colour wheel moving
step
110 - 119 Blackout while gobo wheel moving
step
120-129 Disabled blackout while gobo wheel moving
step
To activate following functions, stop in DMX value for at least 3
seconds:
130 - 139 Lamp On,reset(total reset except pan/tilt reset)
step
140 - 149 Pan/Tilt reset
step
150 - 159 Colour system reset
step
160 - 169 Gobo wheels reset
step
170 - 179 Dimmer/Shutter
step
180 - 189 Zoom/focus/prism reset
step
190 - 199 Reserved
step
200 - 209 Total reset
step
Reserved
Robin Pointe - DMX protocol, version 1.3
(For fixtures produced after 20/08/2013 or updated with a software DSU_RobinPointe_13081258.zip
(DSU_RobinPointe_13081258.tar.bz2) or latter . DSU RobinPointe_YYMMDDTT.zip -->YY=year, MM=month, DD= day)
Mode/channel
DMX
Value
Function
Type of
control
