18. Clarify control.
19. SW external antenna socket.
20. DX/Local switch.
21. FM Stereo & SSB/AM
switch.
22. Headphone socket.
23. DC input socket.
18
4
19
20
24
Volum e Tuning
UpDown
Lo ck
Norm al
News M usic
Clarify
FM St.DX FMLocal
SSB AM
+
+
+
+
DC 6v
SW External
Antenna
FM /SW
21
22
23
25
26
27
24. Tuning control.
25. Tone control.
26. Lock switch.
27. Volume control.
Left hand end Right hand end
