Pop-Up Wizard

The Wizard routine will display factory default settings. Each setting will

display for ten seconds. Use the or buttons to change the

setting. Settings that are not changed will operate with the values that

are displayed. To fast forward through the Wizard, press Edit Schedule.

The Wizard can be exited by pressing Start/Stop Schedule. This will

save the settings and place the thermostat into operation.

Use this chart to write down the desired settings before applying power.

Settings may vary by model.

Displayed Details Default Change To

SCAL choose °F or °C °F _______

CLOC choose 12 or 24 hour 12 _______

LITE y = always on, n = off y _______

DIFF differential, set between 0.5 to 3.0 °F

or 0.5 to 1.5 °C 1 °F _______

DIF2 2nd stage differential,

added to first stage differential 2 °F _______

DLY2 2nd stage delay, in minutes 20 _______

DLY3 3rd stage delay, in minutes 20 _______

AUTO auto changeover enable y _______

DEDB auto changeover deadband

in degrees 3 °F _______

HI heat setting limit in degrees 90 °F _______

LO cool setting limit in degrees 45 °F _______

VAC HEAT vacation heat setpoint in degrees 62 °F _______

VAC COOL vacation cool setpoint in degrees 85 °F _______

CHECK check filter timer in hours n or OFF _______

CYCL compressor short cycle delay in minutes 5 _______

CAL calibration offset in degrees 0 _______

After the Wizard has configured the thermostat, the settings can be

edited by pressing and simultaneously. This will allow you to

change settings.

Factory settings that have not been changed will use the default settings

for operation.
