11
Default EnergyStar™ Settings for
RS5000 and RS6000
The RS5000 and RS6000 series are programmable thermostats and are
preprogrammed with a schedule that is recommended by EnergyStar™.
The schedule is designed to lower energy costs year-round.
Setting Time and Day for the RS5000 and
RS6000 Series
To adjust the time and day settings press the SET TIME button. The hour
will flash. To change the settings:
1. Use the and buttons to change the flashing number.
2. Press the SET TIME button to move through hours, minutes and days
of week.
3. Make changes as needed. They will be saved automatically.
NOTE: The thermostat will not correct for Daylight Saving Time.
Installation Test Utility
WARNING: The installation test procedures
can damage the heating/cooling equipment
if used incorrectly. These procedures
should only be performed by trained
HVAC personnel.
The following instructions may be used to test the heating/cooling
system for correct function.
To enter the test mode press and hold and for five seconds.
Short Cycle protection is disabled when using the test utility.
Push the and or Start/Stop schedule buttons at any time to exit
test mode.
In the test mode:
Press to force the fan on or off.
Pressing repeatedly will allow testing of the system modes. See
following tables. The display will show appropriate animated icons.
EnergyStar™ Temperature Settings
Winter (Heating) Summer (Cooling)
Morning (6:00 am) 70 °F (21 °C) 78 °F (25 °C)
Day (8:00 am) 62 °F (17 °C) 85 °F (29 °C)
Evening (6:00 pm) 70 °F (21 °C) 78 °F (25 °C)
Night (10:00 pm) 62 °F (17 °C) 82 °F (28 °C)
