Robin EH36 User Manual

- 24 -
Fig. 5-13
petSevomerotstraPserudecorpdnaskrameRsrenetsaF
41)noitpO(liocegrahC.liocegrahcehtevomeR.scp2;02x6M
51elffabrednilyC .scp4;8x6M
61gulpkrapSSE6PB;KGN
M6 FLANGE BOLT
: 2 pcs.
STEP 15
STEP 14
STEP 16
STEP 15
M6 SCREW AND WASHER AY
: 2 pcs.
M6 FLANGE BOLT : 2 pcs.
CYLINDER BAFFLE 1
with SPEED CONTROL LEVER AY
CYLINDER BAFFLE 2
SPARK PLUG
CHARGE COIL CP
(
OPTION
)
CLAMP CP
M6 SCREW (PANHEAD) : 1 pce.
