Robin EH36 User Manual

- 1 -
1. SPECIFICATIONS
Specifications are subject to change without notice.
MODEL
EH36
EH36B EH36BS EH36D EH36DS
Type
Air-Cooled, 4-Cycle, Single-Cylinder,
Horizontal P.T.O. Shaft, OHV Gasoline Engine
Bore x Stroke 89 x 65 mm (3.50 x 2.56 in.)
Piston Displacement 404 cm
3
(24.65 cu.in.)
Compression Ratio 8.3
Output
Continuous 6.3 kW (8.5 HP) /1800 r.p.m. 6.3 kW (8.5 HP) /3600 r.p.m.
Max. 8.5 kW (11.5 HP) /1800 r.p.m. 8.5 kW (11.5 HP) /3600 r.p.m.
Max. Torque
54.9 N
・ m(5.60kgf ・ m)
/1250 r.p.m.
27.4 N ・ m(2.80 kgf ・ m)
/2500 r.p.m.
Direction of Rotation Counterclockwise As Viewed From P.T.O. Shaft Side
Cooling system Forced Air Cooling
Valve Arrangement Overhead Valve
Lubrication Splash Type
Lubricant Automobile Oil SAE #20, #30 or 10W-30 ; Class SE or higher
Capacity of Lubricant 1.2 liters (0.32 U.S. gal.)
Carburetor Horizontal Draft, Float Type
Fuel Automobile Unleaded Gasoline
Fuel Consumption Ratio 310 g/kW
・ h(230g/HP ・ h) At Continuous Rated Output
Fuel Feed System Gravity Type
Fuel Tank Capacity 7.0 liters (1.85 U.S. gal.)
Ignition System Flywheel Magneto (Solid State)
Spark Plug NGK BP6ES
Charging Capacity ---------- 12V-1.3A ---------- 12V-1.3A
Starting System Recoil Starter
Electric Starter
& Recoil Starter
Recoil Starter
Electric Starter
&Recoil Starter
Speed Reduction 1/2 Camshaft Drive ----------
Governor System Centrifugal Flyweight Type
Air Cleaner Double Element Type
Dry Weight 32.0 kg (70.6 lb.) 35.0 kg (77.2 lb.) 31.0 kg (68.4 lb.) 34.0 kg (75.0 lb.)
Dimensions (L x W x H) 389 mm x 431 mm x 433 mm (15.31 in. x 16.97 in. x 17.05 in.)
