27
-
Fig. 5-17
Fig. 5-18
MAIN BEARING
COVER CP
GASKET (BEARING COVER)
M8 FLANGE BOLT
(
12T
)
: 7 pcs.
DOWEL PIN : 2 pcs.
STEP 21
Step Parts to remove Remarks and procedures Fasteners
21
Main bearing cover Be careful not to damage the oil seal.
Use a soft hammer and evenly tap
around outer surface of cover.
M8 flange bolt
(12T) x 40;7pcs.
