55
-
9-2-2 COMPORNENT PARTS
Fig. 9-11
THROUGH BOLT (2 pcs.)
REAR COVER
CASE METAL
FRONT METAL
PINION AY
PINION
STOPPER SET
BRUSH
HOLDER
BRUSH (+)
SPRING
(
BRUSH
)
BRUSH (
-
)
WASHER
O RING
WASHER
NUT
SPRING
WASHER
M BUSH 1
YOKE AY
WASHER
ARMATURE AY
FRONT COVER
M BUSH 2
