US
4
Read the owner's manual.
Stay clear of the hot surface.
Exhaust gas is poisonous.
Do not operate in an unventilated area.
Stop the engine before refueling.
Fire, open flame and smoking prohibited.
On (Run) Plus ; Positive polarity
Off (Stop) Battery
Engine oil Engine start (Electric start)
Add oil
SYMBOLS
q SPARK PLUG
w EXHAUST OUTLET
e MUFFLER COVER
r AIR CLEANER
t FUEL TANK
y FUEL TANK CAP (FUEL FILLER)
u SPEED CONTROL LEVER
i RECOIL STARTER
o STARTER HANDLE
!0 CHOKE LEVER
2. COMPONENTS
(See Fig.
11
11
1)
!1 FUEL COCK
!2 FUEL CUP
!3 CARBURETOR
!4 P. T.O. SHAFT
!5 OIL GAUGE (OIL FILLER)
!6 OIL DRAIN PLUG
!7 ENGINE SERIAL NO. (STAMPING)
!8 ENGINE NAME LABEL (SPEC. No.)
!9 STOP SWITCH
NOTE Please refer to the illustrations on the back page of the front
cover or back cover for Fig.
1 1
1 1
1 to
!0!0
!0!0
!0 indicated in the sentence.
