following prog. step
- leaves menu without saving values
7.6 Tab "Service"
Adjust DMX Values - The menu allows you to set all e󰀨ects to desired positions before ne calibration of the
e󰀨ects .
Calibrations - This menu enables ne calibration of xture e󰀨ects and download default calibration values.
Calibrate E󰀨ects - The menu allows the ne adjustment of e󰀨ects.
Pan- a pan position ne adjustment
Tilt - a tilt position ne adjustment
Calibration of the eects via the control board
1. Disconnect DMX controller from the xture and enter the "Calibrate E󰀨ects" menu.
2. Use the [up arrow] and [down arrow] to nd "Pan" and touch it to enter the ne e󰀨ect adjustment screen.
3. Set desired value and save it by touching the [conrm].
4. Repeat steps 2 and 3 for next item
5. After calibrating all e󰀨ects, touch the [conrm] to save all adjusted values and reset the xture.
Calibrate Colours - The menu serves for adjusting of LEDs saturation to achieve uniform white colours
Red - a red LEDs saturation ne adjustment
Green - a green LEDs saturation ne adjusment
Blue - a blue LEDs saturation ne adjustment
White - a white LEDs saturation ne adjustmentt
Calibration of white colours via the control board
1. Disconnect DMX controller from the xture , open shutter and dimmer and set the CTC channel
to DMX=64 (white 5600K), RGBW channels to 255 DMX and Zoom channel to 128 DMX.
2. Set the following items in the menu Personality:
White Point 8000K =On
Colour Mixing Mode=RGBW
3. Aim the light beam on the lux meter (e.g. Minolta CL-200A Chroma meter) which is placed at
min. distance of 3 m from the xture.
4. Enter the menu Calibrate Colours.
5. By means of the Red, green, Blue and White items adjust the 5600K colour temperature as exactly as
possible (∆u´v´= 0).
6. After adjusting 5600K colour temperature, touch the [conrm] to save all adjusted values and reset
the xture.
Calibration protocol:
Eect Mode 1 Mode 2 Mode 3 Mode 4
Pan-ne adjustment channel 49 channel 29 channel 33 channel 91
Tilt - ne adjustment channel 50 channel 30 channel 34 channel 92
Red - red saturation channel 51 channel 31 channel 35 channel 93
Green- green saturation channel 52 channel 32 channel 36 channel 94
Blue - blue saturation channel 53 channel 33 channel 37 channel 95
White - white saturation channel 54 channel 34 channel 38 channel 96
Calibrate Pan/Tilt EMS - This menu item allows calibration of the pan/tilt electronic motion stabilizer.
Important: during this calibration any external force must not inuence the xture and the surface at which
the xture stands (or truss if the xture hangs) has to be without movement, shake, strokes etc.
Load Default Calibrations - The item loads default (factory) calibration values.
Update software - The menu item allows you to update software in the xture via either serial or USB port of PC.
The following are required in order to update software:
