DMX protocol
1 2 3 4
1 1 1 1
Pan (8 bit)
0 - 255 Pan movement by 540° (128=default) proportional
2 2 2 2
Pan Fine (16 bit)
0 - 255 Fine control of pan movement (0=default) proportional
3 3 3 3
Tilt (8 bit)
0 - 255 Tilt movement by 230° (128=default) proportional
4 4 4 4
Tilt fine (16 bit)
0 - 255 Fine control of tilt movement (0=default) proportional
5 5 5 5
Pan/Tilt speed , Pan/Tilt time
0 Max. speed -tracking mode (0=default) step
Pan/Tilt speed
1 - 255 Speed from max. to min. (vector mode) proportional
Pan/Tilt time
1 - 255 Time from 0.1 s to 25.5 sec. proportional
6 6 6 6
Power/Special functions
0 -9 Reserved (0=default)
To activate following functions, stop in DMX value for at least 3 s
and shutter must be closed at least 3 sec. („Shutter,Strobe”
channel 53/27/31/31 must be at range: 0-31 DMX). Corresponding
menu items are temporarily overriden).
10-14
DMX input: Wired DMX
step
15-19
DMX input: Wireless DMX *
step
20-24
Graphic display ON
step
25-29
Graphic display OFF
step
30-34
RGBW colour mixing mode
step
35-39
CMY colour mixing mode
step
40-44
Pan/Tilt speed mode
step
45 - 49
Pan/Tilt time mode
step
50 -54
Blackout while pan/tilt moving
step
55 -59
Disabled blackout while pan/tilt moving
step
60 - 64
Dimmer curve-square law
step
65 - 69
Dimmer curve-linear
step
70 - 74
Fans mode: Auto
step
75 - 79
Fans mode: High
step
80-84
White point 8000K ON
step
85-89
White point 8000K OFF
step
90 -109
Reserved
110-114
Kling-Net On
step
115-119
Kling-Net Off
step
120-129
Reserved
To activate following functions, stop in DMX value for at least 3
seconds.
130 - 139
Fixture reset (except pan/tilt)
140 - 149
Pan/Tilt reset
step
150 - 159
Zoom reset
step
Robin SPIIDER - DMX protocol
Version: 1.6 (10 modes) Mode 1 - 3-zones, Mode 2-Basic, Mode 3 -Advanced, Mode 4 -Full RGBW
Mode/channel
DMX
Value
Function
Type of
control
Page 1
