Introduction
RobinairNo34288isusedonR-134avehiclesandisdesignedtobecompatiblewithexistingservice
equipmentandstandardserviceproceduresModelNo34288isaUL-listed,single-passsystem
thatmeetsSAEspecicationsforrecycledrefrigerantFollowtheSAE-J2211recommendedservice
procedureforthecontainmentofR-134a
Theunitincludesa15cfm(42l/m)Robinairhighvacuumpumpforfast,thoroughevacuationThe
compressorpullstheA/Csystemto0psig,thenworksinserieswiththevacuumpumptoachievehighly
efcientrecoveryandimmediaterechargeIfthesystemisnotopenedforservice,thereisnoneedtopull
additionalvacuumIfthesystemisopenedforservice,usetheunit’svacuumcycletoremoveairand
moisturefromtheA/Csystem(Werecommendaminimum15-minutevacuum,orfollowthevehicle
manufacturer’sspecs)Note: R-134a systems require special oils. Refer to the A/C system manufacturer’s
service manual for oil specications.
Technical Specications
Voltage                           115V,60Hz
Operating Range     50°to120°F(11°to49°C)
Filter-Drier                43cuinspin-ontype
Pump Free-Air Displacement    15cfm(42l/m)
Dimensions
             49"Hx34"Wx23"D
                (1245cmx864cmx584cm)
Digital Display: visual
interface between operator
and machine.
Main Power Switch: supplies
electrical power to unit.
Manifold Gauges:
connect to vehicle A/C system;
show system’s low-side and
high-side pressure.
Tool Storage Area
(additional storage
on back side for
extra lter-driers and
oil bottles).
Panel Valves:
direct system’s low-side
and high-side pressure.
Power Cord
