ROBLIN Virtuose - Assembly View; Display Buttons and Elements

ASSEMBLY VIEW
4-area hob with built-in hood
1
1
2
2
1
1
1 Cooking area
2 Control panel
Display buttons and elements
The controls for the cooking areas, suction hood and timer can be activated by pressing on the reference
Digit .
The Digit lights up more intensely to confirm the operation.
35
Left front cooking
area controls
Left back cooking
area controls
Right back cooking
area controls
Right front cooking
area controls
Power bar
Timer controls
area
Suction hood
controls area
