Robomaid RM-770 - Main Brush Maintenance; Removing and Installing the Main Brush; Cleaning the Main Brush

Main Brush
How to Install the Main Brush
- Hold the brush (the end with the pin must be inserted in the cleaner rst ) See Figure 1.
- Insert the pin shown in Figure 1 into the matching hole in cleaner and push it inward, the other
end of the brush can then be inserted into the gear end. (See Figure 2)
How to Clean the Main Brush
For a better cleaning eect, you must regularly clean out the hair, yarn and large debris wound on or
adhered to the main brush and the dust on the suction inlet .
- Use the cleaning brush to clean paper scraps or minute particles.
- Wound hair, yarn or similar objects should be cut by scissors or pulled out by hand while
carefully rotating the main brush.
How to Remove the Main Brush
- Hold the brush and push it to the left. (See Figure 1)
- The brush will lift out easily. (See Figure 2)
Figure 1
Figure 2
2 erugiF1 erugiF
- Both ends of the main brush be regularly cleaned as lack of maintenance may cause damage.
To ensure a more eective cleaning of the RM-770, please regularly remove and
clean the ends of the main brush thoroughly.
Please clean the main brush after the rst 3 times to judge how often the brush should be cleaned.
Any damage caused by lack of cleaning and maintenance may not be covered under warranty.
Storing the Robomaid RM-770
The Robomaid RM-770 should be stored in ventilated and dry places. Avoid damp areas and direct sunlight.
Remove and Clean the ends
of the Main Brush after each
run for the rst 3 times!
