Robomow RC302 User Manual

28
5.2.4 Main Zone Area
• Scroll to select an approximate area (EU- m² / US- ft²) of
the Main Zone, where the Base Station is installed.
If an additional zone (Sub-Zone or Separated Zone)
exists, do not include it in this area (it will be set
separately).
Note – It is necessary to complete the above settings (5.2.1 –
5.2.3) in order to operate the mower. Every press on the
STOP button will change the screen one step back in the
process.
5.2.5 Test Base Station Position
• After setting the area, U001 (Test Base Station Position)
is displayed.
• Place Robomow inside the lawn, approximately 3 m (10
ft.) in front of the Base Station, facing the Perimeter Wire
and press OK to start the test.
• Robomow drives towards the Base Station:
If the mower does not start the test, then one of
the following messages will be displayed:
E3 ( No Wire Signal ) – Conrm that the Power
Box is connected to the power outlet and that
the Extension Cable is connected at both ends,
from the Power Box to the Base Station.
U029 ( Swap wires in plot connector ) – The
Perimeter Wire has been connected in the
opposite direction. Swap the wires at the plot
connector.
• Robomow will enter the Base Station, drive back, wait in
front of the Base Station, and display U002 ( Peg Base).
If U051 (Reposion Base Staon) message is
displayed:
• Move the Base Station slightly to align it with
the Perimeter Wire.
• Check for any obstacles that may interfere
with the mower’s entrance to the Base
Station.
• While ‘U002’ (Peg Base) is displayed, insert the remaining
Stakes of the Base Station to secure it to the ground and
press OK.
