Robomow RC304u Operation And Safety Manual

34
6.4 Menu Opons
There are several levels of menu options that can be set in your Robomow:
A. Basic Settings
B. Advanced Settings
C. Robomow App Settings
6.4.1 Basic Settings
The Basic Settings are the most common menu options changed by the user. Each of the Basic Settings has an
icon on the mower (refer to 6.2 – Operating Panel) that is lit to indicate the selected menu option.
o To change Basic Settings, press the ‘Settings’ button.
o Every press on the Setting button will move between the following 4 menu options:
6.4.1.1 Day and Time – Set the current Day and Time.
Press the ‘Settings’ button so the ‘Day and Time’ (Clock) icon is constantly lit.
‘Day’ is blinking  Scroll to the required day and press OKtoconrm;
‘Hours’ is blinking  Scroll to the required hour and press OKtoconrm;
‘Minutes’ is blinking  Scroll to the required min and press OKtoconrm;
Note! If the mower is switched off and then back on, the ‘Day’ and ‘Time’ will start blinking to indicate
that the day and the time should be re-set.
6.4.1.2 Mowing Hours (%) – increase/decrease the number of mowing hours (in %) needed to cover the lawn
size.
Press the ‘Settings’ button twice until the ‘Mowing Hours (%)’ LED is constantly lit.
Usethescrollingarrowstoadjustthenumberofmowinghours(in%)andpressOKtoconrm;
The default value of this setting is 100% and it can be changed from 50% to 150%.
Example: a value of 120%, means that Robomow will run 20% more hours on the lawn.
6.4.1.3 Inactive Time – Set times when the mower will be inactive. Inactive operating times can be set for
specicday(s)oftheweek,andforspecichoursforalldaysintheweek.
Inactive Day(s)denestheday(s)whenthemowerwillbeinactive(Default:Sunday).
Inactive HoursdenethehourswhenRobomowwillnotmowandstaysintheBaseStation(Default:
23:00-06:00)
IMPORTANT! It is required to go through the entire Inactive Days and Hours sequence in order to save
the settings. Pressing STOP before completing the whole sequence will not save the settings.
To change the Inactive Time, it is required to perform the following steps:
• Press the ‘Settings’ button 3 times until the ‘Inactive Time’ icon is constantly lit.
• The current Inactive Day(s) will constantly lit.
• Press the OK button; ‘Mon’ will start blinking.
- Press the RIGHT arrow to scroll to the day you want to set.
- Press ‘OK’ to toggle between ‘Active’ and ‘Inactive’ options for that day:
The LED is lit – ‘Inactive Day’ (mower will stay in the Base Station all day).
The LED is off – available day for mowing.
Press the RIGHT arrow to scroll to the next day you want to set
• Scroll through all the days to the right until the ‘Inactive Hours’ will start blinking.
• First set the time, at which the Inactive Hours start and press ‘OK’. Then set the time at which the
Inactive Hours will end.
• Robomow will not operate during the Inactive Hours throughout all days of the week.
• If too many days/hours have been deactivated relative to the zone area, then ‘E8’ (Decrease Inactive
Time) will be displayed – you need to decrease the number of inactive time so that the mower will
have enough time to mow your lawn.
• To set the ‘Inactive Hours’ to ‘Off’ set the same time for the start and the end (i.e.: 00:00 to 00:00).
• Only one window of Inactive Hours can be set in the Basic Settings. To open an additional window of
Inactive Hours use the Robomow App.

Robomow RC304u Specifications

General

Type	Robotic lawn mower
Noise level	69 dB
Cutting width	280 mm
Grass catcher	-
Product color	Green
Cutting system	Rotary blades
Number of wheels	3 wheel(s)
Maximum working climb	36 %
Recommended lawn area	500 m²
Maximum cutting height	60 mm
Minimum cutting height	15 mm
Grass collecting volume	- L
Cutting clearance adjustment	6
Battery type	Built-in
Power source	Battery
Charging time	0.83 h
Battery voltage	26 V
Battery capacity	2.4 Ah
Battery life (max)	50 min
Battery technology	Lithium
Power consumption per month (max)	11 kWh

Weight and Dimensions

Depth	460 mm
Width	630 mm
Height	210 mm
Weight	11400 g
