Robomow RC304u Operation And Safety Manual

38
Screen Seng Descripon Opons
P019
Bluetooth Remote
Control Pairing
• Enables the pairing process between your Robomow and
an outdoor Bluetooth Remote Control that is available as an
accessory (Refer to Paragraph 12 Accessories).
P020
Last Termination
Event
• Enables the Behavior View of the special display (may be required
by a Service Station)
P021
Program On/Off
(Default = ON)
• This menu enables or disables (pauses) Automatic Operation
either in the main zone (‘L1’), one of the Sub-Zones (‘A1/ A2/ A3/
A4’) or in the entire lawn (‘All’).
• This menu is only relevant when the Automatic operation is
enabled on the Power Box (see chapter 7.3)
• When Program is set to Off in a particular zone, the mower will
skip the operation in that zone, but will continue to mow all the
other zones.
• Note! If Program is set to ON at least in one zone, the mower will
continue to mow the edge of the entire lawn at the beginning of
each mowing cycle, as described in Section 6.1.
All
L1
A1
/A2/A3/
A4
On
/OFF
P022
Add Sub-Zone
• Enables the addition of a Sub-Zone. Maximal number of Sub-
Zones may be different for each Robomow model.
• A1/A2/A3/A4(nameoftherstavailablesub-zone)isdisplayed
– press OK.
• If the mower is not at the Base Station, then ‘U044’ (“Place the
mower in the Base Station”) is displayed. Place the mower in the
Base Station and press OK.
• The mower will start moving towards the Sub-Zone.
• Scroll to set the area of the Sub-Zone and press OK.
• Note! This process is not a part of the One-Time Setup (see
Section 5.2)
• The area setting of a Sub-Zone can be later updated through the
‘Area’ menu of the Basic Settings (see Section 6.4.1)
• The distance to Sub-Zone’s entry point can be update later
through menu P023
A1/A2/A3/
A4
100
P023
Update Distance
To Sub-Zone
• ThismenuisshownonlyifaSub-Zonehasbeendened.
• It allows to update the distance to Sub-Zone’s entry point.
• Scroll to choose the required Sub-Zone (A1/A2/A3/A4) and press
OK to update the distance to the entry point.
P024
SmartMow
(Default = OFF)
• SmartMow feature allows more efcient mowing operation
through the smooth and continuous turns when reaching lawn’s
edge.
• When this feature is enabled for the rst time in a particular
zone, it may require the mower to cross the lawn and “touch”
the perimeter wire several times (to perform an initial calibration
of the algorithm), before it will start performing smooth turns at
lawn’s edge.
• Ifthereis more thanone zone dened, thenthere is anoption
to enable this feature for a particular zone or for the entire lawn
(‘All’).
• Please note! Thisfeaturemaynotbeequallyefcientonalllawns
or on different sections of a particular lawn, especially if a lawn
area is small or has narrow areas, big islands or slopes.
All
L1
/L2/L3
A1
/A2/A3/
A4
On
/OFF

Robomow RC304u Specifications

General

Type	Robotic lawn mower
Noise level	69 dB
Cutting width	280 mm
Grass catcher	-
Product color	Green
Cutting system	Rotary blades
Number of wheels	3 wheel(s)
Maximum working climb	36 %
Recommended lawn area	500 m²
Maximum cutting height	60 mm
Minimum cutting height	15 mm
Grass collecting volume	- L
Cutting clearance adjustment	6
Battery type	Built-in
Power source	Battery
Charging time	0.83 h
Battery voltage	26 V
Battery capacity	2.4 Ah
Battery life (max)	50 min
Battery technology	Lithium
Power consumption per month (max)	11 kWh

Weight and Dimensions

Depth	460 mm
Width	630 mm
Height	210 mm
Weight	11400 g
