Roborock F25 - Charging Dock; Basic Parameters

13
1. Power off the vacuum cleaner and place
it in a stable position, then remove the
dirty tank, clean tank, and roller.
2. Clean the roller slot and dirty water
pathway with the provided maintenance
brush.
3. Reinstall the dirty tank, clean tank, and
roller.
Unplug the charging dock and use a
soft, dry cloth to clean its surface and the
charging contacts.
Do not rinse the charging dock directly with water.Note:
Do not rinse the cleaner head directly with water.Note:
D3
Cleaner Head and Dirty
Water Pathway
D4
Charging Dock
Model WD5M1A
Rated Voltage/
Current
21.6 V 9.26 A
Battery
21.6 V/4000 mAh (TYP)
Lithium-ion battery
Vacuum Cleaner
Basic Parameters
Dock Charger
Model MDS16LRR
Rated Input
Voltage
120 V~
Rated
Frequency
60 Hz
Rated Input
(Charging)
0.52 A
Rated Input
(Drying)
6.3 A
Rated Output 30 V 1 A
Charging
Battery
21.6 V/4000 mAh (TYP)
Lithium-ion battery
