12
D9
Moving Dock
Lift up and move the dock. Do not move the
dock by lifting dock base, water tank handles
or dust container cover directly to prevent
the dock from falling o.
Notes:
•
The dust bag handle seals the bag on removal to
prevent leakage.
•
Always install a dust bag before closing the dust
container cover to avoid auto-emptying without the
bag. You can also disable auto-emptying in the app.
D10
Dirty Water Tank
Open the dirty water tank lid and pour out
the dirty water. Fill the tank with clean water,
close the lid, and shake. Pour out the dirty
water. Close the lid and then re-install.
*
Clean as required
D11
Charging Contact Areas
Use a soft dry cloth to wipe the charging
contacts on the robot and the dock.
*
Clean monthly
D12
Replacing Disposable Dust Bag
D12-1—Remove the dust container cover.
D12-2—Remove the disposable dust bag
in the direction of the arrow and
discard it.
*
Replace as required
Model
EWFD11LRR or
EWFD12LRR
Rated Input Voltage 120V~
Rated Frequency 60Hz
Rated Input
(Dust Collection)
7.5A
Rated Input
(Non-Dust Collection)
1.0A
Rated Output 20VDC 1.5A
Battery
14.4 V/5200 mAh
lithium-ion battery
Empty Wash Fill Dock
D12-4—Close the cover of the dust container
and make sure it is securely sealed.
D13
Cleaning Tank
D13-1—Remove the cleaning tank.
D13-2—Rinse the cleaning tank and the
lter with water.
D13-3—Reinstall the cleaning tank.
*
Clean as required
Basic Parameters
Model QX0PEA
Battery
14.4 V/5200 mAh
lithium-ion battery
Rated Input 20VDC 1.5A
Charging Time Approx. 4 hours
Robot
The serial number is on a sticker on the underside
of the robot.
Note:
D12-3—Clean around the lter with a dry
cloth. Install a new disposable dust
bag in place along the slot and
unfold the dust bag to maximize
emptying performance.
To Next Page
