Roborock Q Revo User Manual

14
Common Issues
Unable to power on.
•
The battery level is low. Put the robot on the charging dock and charge it before use.
•
The battery temperature is too low or too high. Only use the robot within the range of 4-40°C (39-104°F).
Unable to charge.
•
Check the power indicator light turns on and both ends of the power cabel are properly connected.
•
If contact is poor, clean the contact areas on the charging dock and the robot.
Slow charging.
•
When used at high or low temperatures, the robot will automatically reduce its charging speed to extend
battery life.
•
The charging contacts may be dirty. Wipe them with a dry cloth.
Unable to dock.
•
There are too many obstacles near the charging dock. Move it to an open area.
•
The robot is too far from the charging dock. Place it closer and retry.
•
The dock locator may be dirty. Wipe them with a dry cloth.
Problem Solution
Noise during cleaning.
•
The main brush, side brush, main wheels, or omni-directional wheel may be jammed. Pause the robot and clean them.
•
The omnidirectional wheel is jammed. Use a screwdriver to remove it for cleaning.
Unable to connect to WiFi.
•
WiFi is disabled. Reset the WiFi and try again.
•
The WiFi signal is poor. Move the robot to an area with good WiFi reception.
•
Abnormal WiFi connection. Reset the WiFi, download the latest mobile app, and retry.
•
Unable to connect to WiFi abruptly. There may be an error with your router settings. Contact Roborock
customer service for additional support.
Is power always being drawn when the robot
is on the charging dock?
•
The robot will draw power while it is docked to maintain battery performance, but power consumption
is minimal.
Does the robot need to be charged for at
least 16 hours the rst three times it is used?
•
No. The robot can be used any time after it has been fully charged.
Cleaning does not resume
after recharging.
•
Make sure that the robot is not in DND mode. DND mode will prevent cleanup.
•
The robot will not resume cleaning if users press
button to recharge or manually place the robot back to the dock.

Roborock Q Revo Specifications

General

Wi-Fi	Yes
Noise level	- dB
Brush material	Rubber
Frequency band	2.4 GHz
Navigation type	Laser Distance Sensor (LDS)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Water tank capacity	0.08 L
Dust capacity (total)	0.35 L
Base station functions	Charging
Vacuum cleaner programs	Around/along obstacles
Battery life	400 m²
Charging time	4 h
Battery voltage	20 V
Battery capacity	5200 mAh
Package type	Box
Package depth	412 mm
Package width	627 mm
Package height	423 mm
Package weight	15300 g
Shape	Round
Product color	White
Dust container type	-
Suction power	5500 Pa

Weight and Dimensions

Depth	96.5 mm
Width	350 mm
Height	353 mm
Weight	3800 g
Base station weight	8600 g
Base station dimensions (W x D x H)	340 x 487 x 561 mm
