The chemical substances contained in the
built-in lithium-ion battery of this product
can cause environmental pollution.
Before disposing of this product, remove
the battery. The battery should then be
properly recycled either through local
authorities or by providing the batteries to a
battery recycling facility.
1. Operate the robot without connecting to
the dock until it runs out of battery.
2. Turn off the robot.
3. Unscrew the battery cover.
4. Remove the battery cover.
5. Press the clip to pull out the battery connector.
6. Remove the battery.
How to remove the battery:
Environmental Protection
Description
Note:
Notes:
The following information is only suitable for the
situation that the robot will be disposed of or its battery
cannot function normally after recharging.
• Before removing the battery, make sure it is fully
drained. Do not attempt to remove the battery if the
robot is connected to the charging dock.
• Remove the entire battery pack. Avoid damaging the
battery pack casing to avoid short-circuits or leakage
of hazardous substances.
• In the event of accidental contact with battery fluid,
rinse thoroughly with water and seek immediate
medical care.
Note: To ensure cleaning performance, replace the filter
components every 1-3 months, depending on the water
quality and how often you use the robot.
C11
Air Duct
*
Clean as required.
Use a soft dry cloth to wipe the charging
contacts on the robot. Clean the dock
location beacon, charging contacts, and
electrode brushes on the dock.
C12
Charging Contact Areas
*
Clean as required.
C11-1—Unscrew the screws (10) and remove
the cover.
C10
Dust Bag Replacement
*
Replace as required.
Note: The dust bag handle seals the bag on removal to
prevent dust leakage.
C10-1—Remove the dustbin cover vertically
as shown.
C10-2— Lift the dust bag out of the dustbin
and discard it.
C10-3— Clean the filter with a dry cloth.
C10-4—Install a new dust bag in place
along the slot and put the dustbin
cover back.
C11-2—Wipe the air duct and cover with a
dry cloth.
C11-3—Reinstall the cover and screw it
back in place.
The robot is equipped with a high-
performance lithium-ion rechargeable
battery pack. To maintain battery
performance, keep the robot charged
during normal use.
Battery
Note: If the robot will be left unused for a long period,
turn it off and charge it at least every three months to
avoid battery damage caused by over-discharge.
C9
Robot Sensors
* Clean monthly.
C9-1—Dock Locator
C9-2—Wall Sensor
C9-3—Four Cliff Sensors
Use a soft, dry cloth to wipe all sensors,
including:
