11
C1-1—Main Brush Cover
C1-2—Latches
C1-3—Main Brush Bearings
C1-4—Main Brush Caps
C1-5—Main Brushes
Restore Factory Settings
If the robot does not function properly after a
system reset, switch it on. Press and hold the
button and at the same time, press the
Reset button until you hear the “Restoring
factory settings” voice prompt. The robot will
then be restored to factory settings.
Note: After resetting the system, scheduled cleaning,
WiFi, etc. will be restored to factory settings.
Clean the main wheels with a soft, dry cloth.
Routine Maintenance
C
*
Clean every 2 weeks and replace every 6-12 months.
C1
Main Brushes
*
Clean monthly.
C4
Main Wheels
C1-6—Turn over the robot and press the
latches to remove the main brush cover.
Pull out the main brush caps.C1-8—
After removing the tangled hair or
dirt at both ends of the main brushes,
reinstall them, press on the main
brush cover to lock it in place until
hear a “click”. Make sure that the main
brush cover has been properly
attached.
C1-9—
Notes:
• Main brushes should be wiped down with a wet cloth
1. Unscrew the side brush screw.
2. Remove and clean the side brush.
Reinstall the brush and tighten the screw.
The omnidirectional wheel bracket cannot be removed.
Note:
Use a tool, such as a small screwdriver,
to pry out the axle and take out the
wheel.
C3-1—
Remove the main brush and pull out
the main brush bearing.
C1-7—
*
Clean monthly and replace every 3-6 months.
C2
Side Brush
*
Clean as required.
C3
Omnidirectional Wheel
Rinse the wheel and the axle with
water to remove any hair and dirt. Dry
and reattach the wheel, pressing it
firmly in place.
C3-2—
C5
Dustbin and Washable Filter
* Clean every week and filter should be replaced every
6-12 months.
Note: To prevent blockage, only use clean water without
any cleaning liquid.
Note: Purchase an additional filter and alternate if
necessary.
Note: Do not touch the surface of the filter with your
hands, brush, or hard objects to avoid potential damage.
C5-1—
Press the dustbin latch and slide the
dustbin backwards.
C5-2—
Remove the washable filter and empty
the dustbin.
C5-3—
Fill the dustbin with clean water.
Gently shake the dustbin, and then
pour out the dirty water.
C5-4—
Rinse the washable filter repeatedly
and tap it to remove as much dirt as
possible.
C5-5—
Leave the dustbin and the washable
filter to dry thoroughly and reinstall
them.
C7
Mop Cloth
* Clean after each use and replace every 3-6 months.
C6
Adjustable Water Tank
* Clean as required.
C6-1—
Open the water tank and fill it with
clean water.
C6-2—
Close the water tank and shake it
gently.
C6-3—
Pour out the remaining water as
shown.
Remove the mop cloth from the mopping
module. Clean and air dry the mop cloth.
Notes:
• After cleaning, always remove the mop cloth to prevent
dirty water from leaching back into the water tank.
• A dirty mop cloth will affect the mopping performance.
Clean it before use.
* Replace them every 1-3 months.
C8
Filter Components
and left to dry away from direct sunlight.
• Do not use corrosive cleaning fluids or disinfectants to
clean the main brushes.
1. Move your finger along the notch to
remove each filter.
2. Insert new filter components and make
sure they are properly installed.
To Next Page
