11
16/01/2020
B) Ejection of pulp into the closed pulp container.
Position the pulp
container
7) Close the safety arm.
To start the machine, press the On button 1. The
juicer will not start unless the safety arm has been
closed properly (safety switch).
Place a jug underneath the spout.
Your juicer is now ready to use!
8) Using the strap (see
page 10) - (Option)
If you have positioned
your juicer on the edge
of a countertop, attach
the ejection chute
to the lid using the
strap supplied with the
appliance.
6) Two possible uses:
A) Continuous pulp ejection.
Position the continuous
pulp ejection chute in
the hole in the booster
base.
Remember to place
a bin (not supplied)
directly beneath this
chute.
For optimum use of the waste discharge hopper
flow-through, you can make a hole in your
worktop.
Dimensions (in mm)
Size of hole to be made in the worktop: 110 mm
