Avatar®IIIUserManualRevD12/2015

3) Closethebatterybaydoorbyreturningthe
doortoitsclosedposition,makingsurethe
foldingbarisfoldedoverthebatteryandthe
upperlipofthebatterydoortucksunderneath
thetopstripofthebatterybay.Shutthelatch
andturnthe“ClosingKnob”clockwise.You
shouldfeela“pop”orclick”whenthebattery
doorhasclosed.
IFFLIPPERSAREBLOCKINGTHEBATTERY
DOOR,MOVEFRONTFLIPPERSANDBACK
FLIPPERS.FRONTANDBACKFLIPPERSMUST
BEMOVEDINPAIRS.DONOTMOVEONE
FLIPPERATATIME.

C) AttachingtheAntennas
Makesurethatthecontrollerantennaisattachedbeforepoweringtheuniton.(Also
makesureyoudon’tpowerontherobotwithouttherobotradioinstalled)
Thecontrollerantennaattachestothe
silverportonthetopleftofthecontroller.
DONOTplugitintothecoveredblackport
onthetoprightsideofthecontroller.If
youhavemorethanoneradio,makesure
youareattachingtheappropriateantenna
fortheradioyouhaveinstalled.The
controllerantennawillbecolor
coordinatedwiththerobotradioantenna.

 DONOTPUTANTENNAONRIGHT
PORT(COVEREDBYBLACKCASING).
DOINGSOWILLPERMANENTLYDAMAGE
YOURCONTROLLER.


Whenclosingthebatterydoor,
makesurethelipatthetopstrip
ofthebatterydoortucks
underneaththetopofthebattery
bay.

