Direct Digital Controller
28 Direct Digital Controller fw 4.013 – Ed. 01/2013
3.3.2 ERROR RESET
To carry out an error reset, follow the instructions below:
1 - Select
from the initial screen to gain access to the main menu.
2 - From the main menu, select
.
3 - Select the plant (
, or if the DDC is configured to manage only one hot/cold plant).
4 - Select the machine, using
or . The unit’s identification number is shown between the arrows.
5 - Position the cursor on
and press the knob to carry out an error reset.
6 - Wait for the operation to be performed. If the operation is successful, the message “OK” appears on the
display.
To exit, select
.
The reset does not perform a flame control unit reset.
It is not possible to reset errors on third party machines.
NOTE
NOTE
