16
Need help? Call 1-800-620-2790 (U.S. and Canada)
3 Insert the concrete wall anchors* into the pilot holes and use a hammer to make sure that
the anchors are flush with the concrete surface.
4 Align the wall plate (A) with the anchors, insert the lag bolts (U) through the lag washers
(T) and the holes in the wall plate, then tighten the lag bolts only until they are firm
against the wall plate.
*Not included. Call Customer Service to inquire about the Fischer UX10 x 60R concrete anchor kit.
CAUTION: Avoid potential injuries or property damage! DO NOT over-tighten the lag
bolts (U).
