RocketFish RF-HTMT15 User Manual

15
Need help? Call 1-800-620-2790 (U.S. and Canada)
RF-HTMT15
1 Align the wall plate template (D) at the height you determined in the previous step and
make sure that it is level. Tape the wall plate template to the wall, then use a pencil to
mark the lag bolt hole locations (3). Remove the wall plate template.
2 Drill pilot holes to a depth of 3 in. (75 mm) using a 3/8 in. (10 mm) diameter masonry drill
bit.
CAUTION: To prevent property damage or personal injury, never drill into the mortar
between blocks. Mount the wall plate directly onto the concrete surface.
3 in.
(75 mm)

RocketFish RF-HTMT15 Specifications

General

Brand	RocketFish
Model	RF-HTMT15
Category	TV Mount
Language	English
