6 Tighten all screws, but do not over-tighten.
You’ll need
F
B
G
P
Q
R
S
N
T
GG
HH
H
or
NOTE: Your existing TV wall mount may vary from the one shown below. Refer to the
instructions that came with your existing TV wall mount for attaching brackets to the back of
the TV. However, you MUST use the screws and washers provided with the soundbar mount
instead of the screws and washers that came with your existing wall mount.
NOTE: The soundbar must
be mounted below your TV.
or
WARNING: You must use the larger
washers (GG or HH) unless they do
not fit your TV bracket.
G (4)
H (4)
P
(4)
Q (4)
R (4)
Phillips screwdriver
or
or
or
S (4)
Level
or
T (4)
F Mount
spacer (2)
B TV bracket
arm (2)
N Spacers (4)
or
or
GG (4)
or
HH (4)
