9
Need help? Call 1-800-620-2790 (U.S. or Canada)
TV WALL MOUNT RF-TVMFM02V2/RF-TVMFM02V2-C
Step 4 Install the horizontal TV brackets
1 Slide the horizontal brackets (D) through the metal guides on the vertical TV
brackets until they are centered.
2 Secure the horizontal TV brackets to the vertical TV brackets using the 8-32 x
9/16" Phillips head screws (V). Tighten the screws until they are snug, but do not
over tighten.
Note: Make sure that the brackets are not covering any jacks or connectors.
You’ll need
V (4) Phillips screwdriver
Horizontal brackets (D)
